Steel / Carbon Steel

Cold Saw Blades for Low and Medium Carbon Steel Cutting

Product Code: CSSA

Cutting speed: 70m/min-120m/min. Tooth load: 0.04-0.1mm/tooth. Cold saw blades designed for cutting low and medium carbon steel, solid material or thick-walled pipes.

Grade:: Industrial
Machines:: Stationary high speed sawing machines
Materials:: Low and medium carbon steel, solid material or thick-walled pipes
Applications:: For sawing low and medium carbon steel

OEM/ODM Materials & Processes

Body Material:: 80CrV2/SKS51
Tips Material:: Cermet
Coating:: None
Tension ring:: Visible or concealed configuration

Typical Specifications

Code	D Diameter (mm)	B Kerf (mm)	b Body (mm)	d Bore (mm)	Z Number of teeth	Tooth type	Pinholes
CSSA0240	240	1.8	1.5	32/40	60	TC	Custom
CSSA0250	250	1.5	1.3	32/40	54	TC	Custom
CSSA0251	250	1.5	1.3	32/40	72	TC	Custom
CSSA0252	250	1.5	1.3	32/40	80	TC	Custom
CSSA0253	250	2.0	1.7	32/40	54	TC	Custom
CSSA0254	250	2.0	1.7	32/40	72	TC	Custom
CSSA0255	250	2.0	1.7	32/40	80	TC	Custom
CSSA0256	250	2.0	1.75	32/40	54	TC	Custom
CSSA0280	285	1.5	1.3	32/40	60	TC	Custom
CSSA0281	285	1.5	1.3	32/40	72	TC	Custom
CSSA0282	285	2.0	1.7	32/40	54	TC	Custom
CSSA0283	285	2.0	1.7	32/40	60	TC	Custom
CSSA0284	285	2.0	1.7	32/40	72	TC	Custom
CSSA0285	285	2.0	1.7	32/40	80	TC	Custom
CSSA0286	285	2.0	1.75	32/40	60	TC	Custom
CSSA0287	285	2.0	1.75	32/40	72	TC	Custom
CSSA0288	285	2.0	1.75	32/40	80	TC	Custom
CSSA0310	315	2.3	2.0	32/40/50	80	TC	Custom
CSSA0360	360	2.0	1.7	32/40/50	60	TC	Custom
CSSA0361	360	2.0	1.7	32/40/50	72	TC	Custom
CSSA0362	360	2.0	1.7	32/40/50	100	TC	Custom
CSSA0363	360	2.5	2.3	32/40/50	80	TC	Custom
CSSA0364	360	2.5	2.3	32/40/50	100	TC	Custom
CSSA0365	360	2.5	2.3	32/40/50	80	TC	Custom
CSSA0366	360	2.5	2.3	32/40/50	100	TC	Custom
CSSA0367	360	2.6	2.3	32/40/50	60	TC	Custom
CSSA0368	360	2.6	2.3	32/40/50	80	TC	Custom
CSSA0369	360	2.6	2.3	32/40/50	100	TC	Custom
CSSA0380	380	2.5	2.3	50	48	TC	Custom
CSSA0381	380	2.5	2.3	50	80	TC	Custom
CSSA0382	380	2.5	2.3	50	100	TC	Custom
CSSA0420	425	2.7	2.3	50	50	TC	Custom
CSSA0421	425	2.7	2.3	50	60	TC	Custom
CSSA0460	460	2.7	2.3	50	40	TC	Custom
CSSA0461	460	2.7	2.3	50	50	TC	Custom
CSSA0462	460	2.7	2.3	50	60	TC	Custom
CSSA0560	560	3.0	2.5	50/80/90/140	44	TC	Custom
CSSA0561	560	3.0	2.5	50/80/90/140	60	TC	Custom
CSSA0750	750	3.4	2.7	50	60	TC	Custom
CSSA0751	750	3.4	2.7	50	80	TC	Custom
CSSA0752	750	3.4	2.7	50	100	TC	Custom
CSSA0753	750	3.4	2.7	50	120	TC	Custom
CSSA0754	750	3.4	2.7	50	140	TC	Custom

Specifications can be tailored to meet customer requirements.

Estimate your material savings: See how a thinner kerf increases workpiece yield with our Short-Stock Material Yield Calculator.

Typical Applications

Cut-to-length sawing of low and medium carbon steel round bar, square bar, flats, and other solid sections on stationary high speed sawing machines.
Thick-walled carbon steel tube and pipe cutting where users want a smooth cut face and stable squareness for downstream machining.
Production of blanks for hydraulic parts, hubs, flanges, bolts, shafts, forged parts, and general mechanical components.
Dedicated high speed circular sawing lines processing low carbon steel, medium carbon steel, and similar non-alloy or low-alloy carbon grades.

Key Performance Advantages

Uncoated cermet tips provide a practical balance of wear resistance, edge stability, and surface finish in low and medium carbon steel cutting.
Supports high-output stationary sawing with cleaner cut surfaces and tighter cut quality than general-purpose steel sawing setups.
Helps reduce burr, heat discoloration, and extra end-face cleanup on routine carbon steel work.
A strong everyday cold saw blade choice when the main target is low to medium tensile carbon steel rather than stainless or high-alloy grades.

Problems This Cold Saw Blade Helps Solve

Short blade life caused by using overly general saw blades on low and medium carbon steel solids.
Rough cut surfaces and poor squareness that increase post-machining time.
Tooth damage caused by unstable clamping, poor chip evacuation, or mismatched speed and feed settings.
Higher process cost on repetitive carbon steel cut-to-length jobs where a dedicated cold saw blade performs more efficiently.

Application Notes

Best suited to low and medium carbon steel grades on stationary high speed sawing machines with rigid clamping, stable feed, and proper coolant supply.
Use effective lubrication and chip evacuation to control heat buildup and protect cermet tooth edges.
This product is not the first choice for stainless steel cutting.
If you need longer life on mixed steel grades or regular cutting of higher carbon and alloy steels, move up to Cold Saw Blades for Steel Cutting.
